Specifications
GPU memory 16GB GDDR6
Memory interface 128-bit
Memory bandwidth 224 GB/s
Error-correcting code (ECC) Yes
NVIDIA Ada Lovelace architecture-based
CUDA Cores
2,816
NVIDIA fourth-generation Tensor Cores 88
NVIDIA third-generation RT Cores 22
Single-precision performance 8.9 TFLOPS2
Ray Tracing performance 20.5 TFLOPS2
Tensor (AI) performance 142 AI TOPS | 142 TFLOPS3
System interface PCIe 4.0 x 84
Power consumption Total board power: 50 W
Thermal solution Active
Form factor 2.7” H x 6.6” L, single slot
Display connectors 4x Mini DisplayPort 1.4a
Max simultaneous displays 4x 4096 x 2160 @ 120 Hz
4x 5120 x 2880 @ 60 Hz
2x 7680 x 4320 @ 60 Hz
Encode/decode engines 1x encode, 1x decode (+AV1 encode and
decode)
Graphics APIs DirectX 12, Shader Model 6.6,
OpenGL 4.65, Vulkan 1.35
Compute APIs CUDA 11.6, OpenCL 3.0, DirectCompute
