| PERFORMANCE |
| Processor |
Intel® Core Ultra 7 255U, 12C (2P + 8E + 2LPE) / 14T, Max Turbo up to 5.2GHz, 12MB Intel Smart Cache |
| AI PC Category |
AI PC |
| NPU |
Integrated Intel® AI Boost, up to 12 TOPS |
| Graphics |
Integrated Intel® Graphics |
| Chipset |
Intel® SoC Platform |
| Memory |
32GB Soldered LPDDR5x-8400 |
| Memory Slots |
Memory soldered to systemboard, no slots, dual-channel |
| Max Memory |
32GB soldered memory, not upgradable |
| Storage |
1TB SSD M.2 2280 PCIe® 4.0x4 NVMe® Opal 2.0 |
| Storage Slot |
Models with U series processor: one M.2 2280 PCIe® 4.0 x4 slot |
| Max Storage Support |
One drive, up to 2TB M.2 2280 SSD |
| Card Reader |
None |
| Audio Chip |
Arrow Lake: High Definition (HD) Audio, Realtek® ALC3306 codec |
| Speakers |
Stereo speakers, 2W x2, Dolby Atmos® |
| Microphone |
2x, 360° |
| Camera |
FHD 1080p + IR Discrete with Privacy Shutter |
| Battery |
57Wh |
| Power Adapter |
65W USB-C® Slim GaN (3-pin) |
| DESIGN |
| Display |
14" WUXGA (1920x1200) IPS 500nits Anti-glare, 100% sRGB, 60Hz, Low Power |
| Touchscreen |
None |
| Screen-to-Body Ratio |
89.2% |
| Pen |
Pen Not Supported |
| Keyboard |
Backlit, Hungarian |
| Touchpad |
Haptic Touchpad |
| Dimensions (WxDxH) |
312.80 x 214.75 x 8.38/14.77 (front/rear), 17.95 (maximum) mm; 12.31 x 8.45 x 0.33/0.58 (front/rear), 0.71 (maximum)inches |
| Weight |
Starting at 1006 g (2.22 lbs) |
| Case Color |
Black, Paint |
| Case Material |
Carbon Fiber (Top), Aluminium (Bottom) |
| SOFTWARE |
| Operating System |
Windows® 11 Pro, Hungarian / English |
| Bundled Software |
Intel® Connectivity Performance Suite |
| CONNECTIVITY |
| WLAN + Bluetooth |
Intel® Wi-Fi® 6E AX211, 802.11ax 2x2 + BT5.3 |
| WWAN |
WWAN Upgradable to 4G or 5G |
| SIM Card |
None |
| Ethernet |
No Onboard Ethernet |
| NFC |
None |
| Standard Ports |
- 1x USB-A (USB 5Gbps / USB 3.2 Gen 1)
- 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
- 2x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps), with USB PD 3.0 and DisplayPort™ 2.1
- 1x HDMI® 2.1, up to 4K/60Hz
- 1x Headphone / microphone combo jack (3.5mm)
|
| Optional Ports (configured) |
1x Nano-SIM Card Slot |
| Docking |
Various docking solutions supported via Thunderbolt™ / USB-C®. For more compatible docking solutions, please visit Docking for ThinkPad X1 Carbon Gen 13 Aura Edition |
| SECURITY & PRIVACY |
| ThinkShield |
ThinkShield is a comprehensive security solution that encompasses hardware, software, and supply chain components. For more detials, visit here |
| Security Chip |
Discrete TPM 2.0 Enabled |
| Physical Locks |
Kensington® Nano Security Slot, 2.5 x 6 mm |
| Smart Card Reader |
None |
| Fingerprint Reader |
Touch Style, Match-on-Chip, in Keyboard Key |
| Other Security |
- Camera privacy shutter
- Ultrasonic Human Presence Detection
- IR camera for Windows® Hello (facial recognition)
|
| MANAGEABILITY |
| System Management |
Non-vPro® |
| SERVICE |
| Base Warranty |
3-year, Courier or Carry-in |
| Included Upgrade |
3Y Premier Support WHB (CPN), CO2 Offset 0.5 ton (2nd Generation Carbon Offset Projects) |
| ACCESSORIES |
| Bundled Accessories |
None |
| CERTIFICATIONS |
| Green Certifications |
- ENERGY STAR® 9.0
- EPEAT™ Gold Registered
- ErP Lot 6/26
- RoHS compliant
- TCO Certified, generation 10
|
| Mil-Spec Test |
MIL-STD-810H military test passed |
| Other Certifications |
- Eyesafe® Certified 2.0
- Intel® Evo™ Platform
- SGS High Performance Al PC Certification
|
| MODEL INFORMATION |
| Model |
21NX00FPHV |
| Machine Type |
21NX |
| Region |
EET |
| Country/Region |
Hungary |
| TopSeller |
Yes |
| EAN / UPC / JAN |
0199272048305 |
| Announce Date |
2025-06-30 |
| End of Support |
2031-11-18 |
